Alloy Steel Grease Injection Control Head with 10000psi Working Pressure and Hammer Union Connection for Wireline Operations

Minimum Order Quantity :	1 set	Price :	USD 1-10000/set
Packaging Details :	Pollywood	Delivery Time :	30-50 days
Payment Terms :	L/C,T/T,D/P	Supply Ability :	10 set/month

Place of Origin:	China	Brand Name:	ZZ TOP OIL TOOLS
Certification:	ISO, API	Model Number:	Grease Injection Control Head

Detail Information
Product:	Grease Injection Control Head	Material:	Alloy Steel
Working Pressure:	10000psi	Application:	Wireline Operation
Usage:	Wireline Pressure Control Equipment	Connection:	Hammer Union
Wokring Temp.:	-29～121℃
Highlight:	10000psi Grease Injection Control Head , Hammer Union Grease Injection Control Head , Alloy Steel Wireline Pressure Control Equipment

Product Description

Grease Injection Control Head Assembly with Stuffing box and Wireline Wiper

The Grease Injection Control Head is a sealing device designed for braided cable wireline operations, providing effective wireline sealing functionality. This essential component is used across various oil and gas well applications where pressure control is critical during wireline operations, particularly when fluid or gas loss cannot be tolerated.

Key Features

Positioned at the top of the pressure control equipment string
Combines Line Wiper Bell, Stuffing Box, Flow Tubes assembly, and ball check valve
Essential for maintaining well integrity during high-pressure operations

Technical Specifications

Wire Size	Working Pressure	Qty. Of Stuffing Box	Qty. Of Flow Tubes	Qty. Of Hydraulic Port	Qty. Of Grease Injection Port	Qty. Of Grease Return Port	Service	Working Temperature
7/32" 5/16" 15/32"	5000Psi	1	4	2	1	1	STD or H2S	P+U -20°F~+250°℉ Or As Required
	10000Psi	1	6	2	1	1
	15000Psi	2	9	3	2	1
