Full Bore Retrievable Mechanical Well Packers High Pressure RTTS For DST Service

Minimum Order Quantity : 1 set Price : USD 1-10000/set
Packaging Details : Pollywood Delivery Time : 30-50 days
Payment Terms : L/C, T/T, D/P Supply Ability : 10 set/month
Place of Origin: China Brand Name: ZZ TOP OIL TOOLS
Certification: ISO, API Model Number: APR Tools

Detail Information

Product: Full Bore Retrievable Packer Material: Alloy Steel / Inconnel
Size: 4 1/2 Inch To 20 Inch Working Pressure: 10000psi
Application: Oil & Gas Well Dowhole Drill Stem Testing Service Connection: IF, EUE , CAS
Working Condition: Oil & Gas & H2S Service Working Temperature: Up To 425oF
High Light:

Full Bore mechanical well packers

,

Retrievable mechanical well packers

,

10000psi RTTS Packer

Product Description

Full Bore Retrievable Packer High Pressure RTTS Packer For DST Service



The Full Bore Retrievable Packer is a part of Drill Stem Testing Tool String,  this retrievable packer is also called RTTS Packer in Halliburton type. The retrievable packer is designed with a full opening, which is hookwall type packer for use in testing, treating, and squeeze cementing operations. The full opening permits pumping large volumes of fluid with a minimum pressure drop, and allows the passage of a through tubing type perforating gun. This helps make the tool usable for multiple operations with one trip in the hole-such as perforate, test, treat, squeeze, perforate, etc. Generally, the tool is composed of a packer body assembly and circulating valve assembly. It may also includes a safety joint.







Specifcation of Full Bore Retrievable Packer / RTTS Packer



Size(in) Casing Range(lb/ft) Size(in) Casing Range(lb/ft)



4 1/2

9.5 8 5/8 24-49
15.1-18.1



9 5/8

40-71.8
11.6-13.5 29.3-53.5



5

23



10 3/4

32.75-55.5
15-18 60.7-81
11.5-13



11 3/4

38-54



5 1/2

23-26 60-71
20-23



13 3/8

48-72
13-20 72-98
6 15-23



16

75-109
6 5/8 24-32 109-146



7

17-38 18 5/8 78-118
49.5



20

94-133
7 5/8 20-39 169-204
