High Performance Sliding Sleeve Doors / SSD For Well Completion Operations

Name: High Performance Sliding Sleeve Doors / SSD For Well Completion Operations
Brand: ZZ TOP OIL TOOLS
SKU: Sliding Sleeve Doors
Price: 1 USD
Availability: InStock
Rating: 5 (188 reviews)

Minimum Order Quantity :	1 set	Price :	USD 1-10000/set
Packaging Details :	Pollywood	Delivery Time :	30-50 days
Payment Terms :	L/C, T/T, D/P	Supply Ability :	10 set/month

Place of Origin:	China	Brand Name:	ZZ TOP OIL TOOLS
Certification:	ISO, API	Model Number:	Sliding Sleeve Doors

Detail Information
Product:	Sliding Sleeve Doors	Application:	Oil & Gas Well Completion Operation
Usage:	Downhole Flow Control Component	Tubing Size:	2 3/8" - 4 1/2"
Working Pressure:	7500 Psi	Connection:	IF, EUE , CAS
Working Condition:	Oil & Gas & H2S Service	Working Temperature:	Up To 425oF
High Light:	SSD Well Completion Tools , Well Completion Operations Sliding Sleeve Doors , High Performance Sliding Sleeve Doors

Product Description

High Performance Sliding Sleeve Doors / SSD For Well Completion Operations

The Sliding Sleeve doors / SSD are high performance and equalizing sliding sleeves which provide the communication between the tubing and annulus for circulation or production. The sliding sleeve doors is one of common downhole flow control devices in well completion and production. When desired, the sleeve can be shifted open or closed using standard slickline operations and a B Type shifting tool.

Features and Benefits:

The Body can be designed for several standard material, such as low cabon alloy steel, 9Cr, 13Cr, and Inconel 718 for wide range applications.
The flow area is not less than the tubing ID area with the same size.
Equalizing mechanism equalize the differential pressure before opening to protect the sealing elements.
Weight indicating on the close, equalizing, oepn positions.

Technical parameter of Sliding Sleeve Doors

Tubing size	2.375	2.875	3.500	4.500
Seal bore size	1.875	2.312	2.813	3.75
Max.OD	3.09	3.75	4.5	5.5
Max.Shifting Diff.pressure	1500	1500	1500	1500
Pressure rating	7500	7500	7500	7500
OVL	49	48.6	50	58

High Performance Sliding Sleeve Doors / SSD For Well Completion Operations 0
