WHPH Hydraulic Set Retrievable Packer Well Completion Tools High Pressure Packer

Minimum Order Quantity : 1 set Price : USD 1-10000/set
Packaging Details : Pollywood Delivery Time : 30-50 days
Payment Terms : L/C, T/T, D/P Supply Ability : 10 set/month
Place of Origin: China Brand Name: ZZ TOP OIL TOOLS
Certification: ISO, API Model Number: WHPH Hydraulic Set Retrievable Packer

Detail Information

Product: WHPH Hydraulic Set Retrievable Packer Application: Oil & Gas Well Completion System
Usage: Single-trip Completion Casing Size: 7" - 9 5/8"
Working Pressure: 15000 Psi Connection: IF, EUE , CAS
Working Condition: Oil & Gas & H2S Service Working Temperature: Up To 425oF
High Light:

Single Trip Hydraulic Set Retrievable Packer


Well Completion High Pressure Packer


Hydraulic Set Retrievable High Pressure Packer

Product Description

Well Completion Tools WHPH Hydraulic Set Retrievable Packer


The WHPH hydraulic set retrievable packer is a kind of barrel slip, retrievable packer which can be set by hydraulic set with a plug below and released by special retrieving tool. This packer incorporates unique design features that result in a retrievable packer suitable for use at differential pressures up to 15ksi at temperature up to 400〫F . The barrel slip uniformly distributes the packer to casing loads. The propped element package reliably seals the high pressures and can be retrieved with the packer.


Features and Benefits:

  • The Hydraulic Set Retrievable Packer is featured with propped element package;
  • Barrel slip of hydraulic set retrievable packer helps minimum casing damage or deformation;
  • Slip located below element for protection from debris;
  • No mandrel movement operation, multi-packer installations;
  • Also available as cut to release option

Technical parameter of Hydraulic Set Retrievable Packer


WHPH Hydraulic-set Retrievable Packer
Casing Size Casing Weight Packer OD Packer ID
in Lbs/ft in in
7 26-32 5.92 3.80
29-32 5.92 3.72
32-35 5.82 3.72
35-38 5.73 2.75
7 5/8 39 6.405 2.972
47.1 6.125 3.32
9 5/8 47~53.5 8.35 5.80

WHPH Hydraulic Set Retrievable Packer Well Completion Tools High Pressure Packer 0
