Seal Bore Retrievable Packer / Barrel Slip Well Completion Tools 4 1/2" - 9 5/8"

Name: Seal Bore Retrievable Packer / Barrel Slip Well Completion Tools 4 1/2" - 9 5/8"
Brand: ZZ TOP OIL TOOLS
SKU: WVBA Seal Bore Retrievable Packer
Price: 1 USD
Availability: InStock
Rating: 4.8 (163 reviews)

Minimum Order Quantity :	1 set	Price :	USD 1-10000/set
Packaging Details :	Pollywood	Delivery Time :	30-50 days
Payment Terms :	L/C, T/T, D/P	Supply Ability :	10 set/month

Place of Origin:	China	Brand Name:	ZZ TOP OIL TOOLS
Certification:	ISO, API	Model Number:	WVBA Seal Bore Retrievable Packer

Detail Information
Product:	WVBA Seal Bore Retrievable Packer	Application:	Oil & Gas Well Completion System
Usage:	Down Hole Water Injection, Hydraulic Fracturing, Perforating	Casing Size:	4 1/2" - 9 5/8"
Working Pressure:	5000psi -10000psi	Connection:	IF, EUE , CAS
Working Condition:	Oil & Gas & H2S Service	Working Temperature:	Up To 425oF
High Light:	Well Completion Tools 9 5/8" , Barrel Slip Retrievable Packer , Seal Bore Retrievable Packer

Product Description

Well Completion Tools Seal Bore Retrievable Packer / Barrel Slip

The WVBA seal bore retrievable packer is a kind of barrel slip, retrievable packer which can be set by special setting tool and released by special retrieving tool. It is used in down hole water injection, hydraulic fracturing, perforating, hanger packer of open hole horizontal well completion system and effectively avoid the risks of normal hanger packer setting in advance. It can also be used as a heel packer in sand control application.

Features and Benefits:

The Seal Bore Retrievable Packer is designed to withstand 10,000PSI[69.0MPa] differential pressure;
A ratchet lock ring secure dynamic and long-lasting setting force;
The barrel slip is safe and reliable;
Effectively anchored to any part of the casing;

Technical parameter of Seal Bore Retrievable Packer

Specification
Casing OD	Casing Weight	Max.OD	Min.ID
in	Lbs /ft	in	in
4 1/2	12.75	3.74	1.79
5 1/2	20-23	4.50	2.81
6 5/8	20-24	5.47	2.96
7	20-26	5.88	3.88
	23-29	5.88	4.00
	23-29	5.88	3.88
	26-32	5.75
	32-38	5.69
7 5/8	39	6.38	4.33
9 5/8	40-47	8.38	6.00

Seal Bore Retrievable Packer / Barrel Slip Well Completion Tools 4 1/2" - 9 5/8" 0
