Ratch Latch Seal Assembly With Anchor Mechanism For Well Production

Product Description

Ratch Latch Seal Assembly With Anchor Mechanism For Well Production

The Latch Seal Assembly is used to lock into a polish bore with seals and be held in place with a ratching latch system. The WRL Ratch Latch Seal Assembly has anchor mechanism running into packer seal bore or BPR. This positive latch system minimizes seal movement in the well.

The seals isolate production tubing and annulus by locating in a seal bore assembly or seal bore packer with the receptacle profile for the latch system.

Features and Benefits:

• The Latch Seal Assembly can withstand up to 15,000PSI[103.5MPa] of internal and external pressure difference;
• Withstand temperatures up to 400℉[204℃];
• The seal assembly type and material can be changed to meet the specify a service environment;
• The Latching Seal Assembly is available in various sizes meeting the requirements for most final completion designs.

Technical parameter of Ratch Latch Seal Assembly
