10000psi VR Safety Joint For Drill Stem Testing Tools 5" X10000psi

Minimum Order Quantity : 1 set Price : USD 1-10000/set
Packaging Details : Pollywood Delivery Time : 30-50 days
Payment Terms : L/C, T/T, D/P Supply Ability : 10 set/month
Place of Origin: China Brand Name: ZZ TOP OIL TOOLS
Certification: ISO, API Model Number: VR Safety Joint

Detail Information

Product: VR Safety Joint Type: APR Tools
Size: 5 Inch Working Pressure: 10000psi
Application: Oil Well Downhole Testing Service Connection: IF, EUE , CAS
Working Condition: Oil & Gas & H2S Service Working Temperature: Up To 425oF
High Light:

10000psi Drill Stem Testing Tools


Drill Stem Testing Tools 5" X10000psi


10000psi VR Safety Joint

Product Description

VR Safety Joint For Drill Stem Testing Service 5" x10000psi

VR Safety joint is a compact, right-hand safety joint used in the drill stem testing string. It is run immediately above the packer assembly to ensure that a minimum number of tools are left in the hole if it becomes necessary to release the safety joint. The tool’s bypass feature acts as an auxiliary to the Hydrospring tester bypass to allow fluid to pass though the packer while the work string is being pulled out of the hole.
A spline and lug arrangement, joining the male and female parts of the left-hand safety joint thread, lock to prevent unintentional back-off from the tool during normal manipulation of the drill pipe during testing. Because of the spline and lug configuration, the slips must be dropped in place before the drill pipe is lowered after every stand of pipe is pulled out of the hole.
Technical parameter of
Tension Sleeve RTTS Safety Joint


1 Nominal Size 5”
2 OD 127.5mm
3 ID 25mm
4 Length 963mm
5 Working Pressure 70Mpa(10000psi)
6 Tensile Strength 1628KN
7 Burst Pressure 113.6Mpa
8 Collapse Pressure 150Mpa
9 Torque Strength 15kN.m
10 Working Temp. -29oC~180oC
11 Service H2S NACE MR0175(Above 175F)
12 Connection Thread EUE/IF/CAS
13 Througth Area 1700mm2

   10000psi VR Safety Joint For Drill Stem Testing Tools 5" X10000psi 0  10000psi VR Safety Joint For Drill Stem Testing Tools 5" X10000psi 1
