APR 5 Inch Drill Stem Testing Tools Sleeve Type Drain Valve For Well Testing
Contact Person : LEE
Phone Number : 86-13659253658
WhatsApp : +8613659253658
| Minimum Order Quantity : | 1 set | Price : | USD 1-10000/set |
|---|---|---|---|
| Packaging Details : | Pollywood | Delivery Time : | 30-50 days |
| Payment Terms : | L/C, T/T, D/P | Supply Ability : | 10 set/month |
| Place of Origin: | China | Brand Name: | ZZ TOP OIL TOOLS |
|---|---|---|---|
| Certification: | ISO, API | Model Number: | APR Tools |
|
Detail Information |
|||
| Product: | Drill Stem Testing Tool String / DST Tool String | Material: | Alloy Steel / Inconnel |
|---|---|---|---|
| Size: | 5inch | Working Pressure: | 10000psi / 15000psi |
| Application: | Oil & Gas Well Dowhole Testing Service | Connection: | IF, EUE , CAS |
| Working Condition: | Oil & Gas & H2S Service | Working Temperature: | Up To 425oF |
| Highlight: | Inconnel WellDrill Stem Testing Tools 5inch,Inconnel 5inch Downhole Drill Stem Testing Tools,Inconnel 400F dst drill stem test |
||
Product Description
Oil & Gas Well Downhole Drill Stem Testing Tools String APR DST Tools String
The Drill Stem Testing Tools / DST tools manufactured by ZZ Top is full bore type and annular pressure operated, applicable for 4 1/2” to 20” casing, the tools OD is 3 7/8” and 5”, Working pressure upto 105Mpa, working temperature upto 425F.
As per NACE MR0175 standard, the materials ZZ Top used is AISI41XX Alloy steel with hardness in 30HRC in average but also consider the high working pressure to choose high hardness material used in Critical parts i.e. Nitrogen Case, for ball valve, the material is Inconel 718. And for strict working condition such as high H2S, CO2, Acid and HCL, we also suggest the material Inconnel or other high Nickel alloy steel.
Specifcation of Drill Stem Testing tool String
| Name | Size | Specification |
| RTTS Packer | 4 1/2”-20” Casing | 70Mpa, 400F |
| CHAMP IV Packer | 7”-13 3/8” Casing | 70Mpa,400F |
| Champ XHP Packer | 7”-13 3/8” Casing | 105Mpa, 400F |
| RTTS Circulating Valve | 4 1/2”-20” Casing | 70Mpa, 400F |
| IPO Circulating Valve | 5” OD | 105Mpa 400F |
| Hydraulic Circulating Valve | 3 7/8” and 5” OD | 105Mpa 400F |
| RD Safety Circulating Valve | 3 7/8” and 5” OD | 105Mpa, 400F |
| RD Circulating Valve | 3 7/8” and 5” OD | 105Mpa, 400F |
| OMNI Circulating Valve | 3 7/8” and 5” OD | 105Mpa, 400F |
| RTTS Safety Joint | 4 1/2”-20” Casing | 105Mpa, 400F |
| Round mandrel slip joint | 3 7/8” and 5” OD | 105Mpa, 400F |
| TST Valve | 3 7/8” and 5” OD | 105Mpa, 400F |
| RD Sampler | 3 7/8” and 5” OD | 105Mpa, 400F |
| Drain valve | 3 7/8” and 5” OD | 105Mpa, 400F |
| LPR-N Valve | 3 7/8” and 5” OD | 105Mpa, 400F |
| Select tester valve | 3 7/8” and 5” OD | 105Mpa, 400F |
| Hydraulic Jar | 3 7/8” and 5” OD | 105Mpa, 400F |
| Gauge Carrier | Design as per Gauges | 105Mpa, 400F |
| Radial shock absorber | 7”Casing | 105Mpa, 400F |
| Vertical Shock Absorber | 5” OD | 105Mpa, 400F |
| Super Safety Valve | 8” OD | 105Mpa, 400F |
