7 Inch 10000psi Well Completion Tools

Product Details:
Place of Origin:	China
Brand Name:	ZZ TOP OIL TOOLS
Certification:	ISO, API
Model Number:	SVB Squeeze Packer
Payment & Shipping Terms:
Minimum Order Quantity:	1 set
Price:	USD 1-10000/set
Packaging Details:	Pollywood
Delivery Time:	30-50 days
Payment Terms:	L/C,T/T,D/P
Supply Ability:	10 set/month

Contact Now

Detail Information
Product:	SVB Squeeze Packer	Application:	Oil Well Cementing Operation
Usage:	Well Pressure Control	Size:	7 Inch
Working Pressure:	10000psi	Connection:	IF
Working Condition:	Oil & Gas & H2S Service	Working Temperature:	Up To 425oF
Highlight:	7 Inch Squeeze Packer , 10000psi Drillable Bridge Plug , High-Temperature Cement Retainer

Product Description

Squeeze Packer / Drillable Bridge Plug / Cement Retainers 7"x 10000psi working pressure

Product Overview

The Squeeze Packer is a high-temperature/high-pressure sliding-valve used in remedial cementing operations. It can also function as a drillable bridge plug and cement retainer. Constructed from cast iron, brass, aluminum, and rubber for optimal drillability.

Key Features

Controls flow and pressure differential in either direction
Allows pressure testing of workstring
Slips designed for all grades of casing
Top-drilling bridge plug conversion capability
Pressure venting feature for safer drilling/milling

Technical Specifications

Parameter	Value
Applicable Casing size	6 5/8"17-24# 7" 20-38# 7 5/8" 45.3-55.3# 7 3/4"53.52#
Max. Casing ID	164.1mm
Max. OD	139.7mm
Length	802mm
Max. Differential Pressure	10000psi
Working Temperature	-29°C~120°C
Tension Sleeve Value	40000lbs/25000lbs/30000lbs
