1 1/2" Slip Connector Coiled Tubing Tools

Product Details:
Place of Origin: China
Certification: ISO, API
Model Number: Internal Slip Connector
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 1-10000/set
Packaging Details: Pollywood
Delivery Time: 30-50 days
Payment Terms: L/C, T/T, D/P
Supply Ability: 10 set/month

Detail Information

Product: Internal Slip Connector Application: Coiled Tubing Tools
Usage: Downhole Coiled Tubing Operation Material: Alloy Steel
Size: 1 1/2" - 2" Connection: AMMT, PAC
Working Condition: Oil & Gas & H2S Service Delivery: 20-30 Days
High Light:

2in Coiled Tubing Tools


Gas Coiled Tubing Tools


1 1/2" Slip Connector

Product Description

Internal Slip Connector / Internal Grapple Connector For Coiled Tubing Tool String
Internal Grapple Connector is connected to the coiled tubing by slips. It is the solution for torque and high tensile loads. It can be used for sand washing, gas lifting, and it is recommended when there is necking in the well. Unlike existing slip connectors, the Internal Slip Connector does not rely on grub screws to transmit torque from the toolstring through to the coiled tubing. This feature is provided through a unique non-rotational slip arrangement providing high bi-directional torque resistance. The slip is positively engaged into the bottom sub via drive teeth, therefore transmitting any rotational torque from the toolstring directly to the pipe. The Internal Slip Connector is designed with dual seal which make sure the high pressure seal ability.

Specification of Internal Slip Connector


CT Size Max. OD(in) Min. ID

Slip Load Capacity

(QT 800) T

1 1/2” 1.500 0.625 6.35 1” AMMT
1 3/4” 1.750 0.680 8.60 1” AMMT
2” 2.000 0.870 7.25 1 1/2” AMMT

 1 1/2" Slip Connector Coiled Tubing Tools 0
