7 Inch 10000psi High-Temperature Squeeze Packer and Drillable Bridge Plug for Oil Well Cementing
7 Inch 10000psi High-Temperature Squeeze Packer and Drillable Bridge Plug for Oil Well Cementing 7 Inch 10000psi High-Temperature Squeeze Packer and Drillable Bridge Plug for Oil Well Cementing
Contact Now

7 Inch 10000psi High-Temperature Squeeze Packer and Drillable Bridge Plug for Oil Well Cementing

Minimum Order Quantity : 1 set Price : USD 1-10000/set
Packaging Details : Pollywood Delivery Time : 30-50 days
Payment Terms : L/C,T/T,D/P Supply Ability : 10 set/month
Place of Origin: China Brand Name: ZZ TOP OIL TOOLS
Certification: ISO, API Model Number: SVB Squeeze Packer

Detail Information
Product: SVB Squeeze Packer Application: Oil Well Cementing Operation
Usage: Well Pressure Control Size: 7 Inch
Working Pressure: 10000psi Connection: IF
Working Condition: Oil & Gas & H2S Service Working Temperature: Up To 425oF
Highlight:

7 Inch Squeeze Packer

,

10000psi Drillable Bridge Plug

,

High-Temperature Cement Retainer

Product Description

Squeeze Packer / Drillable Bridge Plug / Cement Retainers 7"x 10000psi working pressure
Product Overview

The Squeeze Packer is a high-temperature/high-pressure sliding-valve used in remedial cementing operations. It can also function as a drillable bridge plug and cement retainer. Constructed from cast iron, brass, aluminum, and rubber for optimal drillability.

Key Features
  • Controls flow and pressure differential in either direction
  • Allows pressure testing of workstring
  • Slips designed for all grades of casing
  • Top-drilling bridge plug conversion capability
  • Pressure venting feature for safer drilling/milling
Technical Specifications
Parameter Value
Applicable Casing size 6 5/8"17-24#
7" 20-38#
7 5/8" 45.3-55.3#
7 3/4"53.52#
Max. Casing ID 164.1mm
Max. OD 139.7mm
Length 802mm
Max. Differential Pressure 10000psi
Working Temperature -29°C~120°C
Tension Sleeve Value 40000lbs/25000lbs/30000lbs
